Frontend

You can find frontend files under src/frontend. The frontend is built with Vue.js. After first run with docker-compose up dependencies will be installed automatically. If you want to install dependencies manually, you can run npm install under src/frontend folder.

Folder Structure

When adding new files to the project, please adhere to the following folder structure:

• Creating New Modules: Modules are the components used in pages. For example, the Client module holds components related to clients. Every component associated with clients should be placed under the Client module.

src/frontend
├── src
│   ├── modules
│   │   ├── newModule

• Creating New Pages: Pages are the components used in routes. We follow the nuxt.js folder structure for pages. The index.vue file under a page folder represents the listing page of the page, while the _id.vue file represents the detail page. Since we are not using nuxt.js, routes need to be defined manually. You can find the routes in the src/frontend/src/ExportedRoutes.js file.

src/frontend
├── src
│   ├── pages
│   │   ├── newPage
|   |   |   ├── index.vue
|   |   |   ├── _id.vue

Translations (i18n)

The frontend uses vue-i18n for internationalization. All user-facing text should come from translation files rather than being hardcoded.

How it works

Translation strings live in JSON files under src/frontend/src/assets/locales/. Each supported language has its own file (en.json, fr.json, pt.json, etc.). These are imported in src/frontend/src/i18n.js and registered with vue-i18n. The user's selected language is persisted in localStorage and can be changed from Settings → Configuration → Language.

File structure at a glance

src/frontend/src/
├── i18n.js                          # vue-i18n setup, imports all locale files
├── bootstrap.js                     # VeeValidate dictionary (form validation messages)
├── assets/locales/
│   ├── en.json                      # English (source of truth)
│   ├── fr.json                      # French
│   ├── pt.json                      # Portuguese
│   ├── ar.json                      # Arabic
│   └── bu.json                      # Burmese
└── modules/Settings/Configuration/
    └── MainSettings.vue             # language selector dropdown

Translation key format

The JSON files use a flat-ish structure with four top-level sections:

Section	Purpose	Example key
errors	Error messages shown to the user	errors.alreadyUsedCompanyEmail
menu	Navigation menu labels (includes subMenu)	menu.Dashboard, menu.subMenu.Settings
messages	Toast / notification messages	messages.successfullyCreated
phrases	Longer UI labels, descriptions, multi-part strings	phrases.newAgent
words	Single words reused across the UI	words.save

Pluralization and multi-part strings use the pipe (|) separator:

"appliance": "Appliance | Appliances"
"addReceipt": "Add Receipt | Receipt Added successfully | This agent does not owe the energy provider. "

Interpolation uses curly braces:

"paymentAmountCannotBeLess": "Payment amount cannot be less than {amount}"

Using translations in Vue components

<!-- Simple key -->
<span>{{ $t('words.save') }}</span>

<!-- With interpolation -->
<span>{{ $t('messages.paymentAmountCannotBeLess', { amount: 100 }) }}</span>

<!-- Pluralization (0 = first form, 1 = second form, etc.) -->
<span>{{ $tc('words.appliance', 1) }}</span>
<!-- "Appliance" -->
<span>{{ $tc('words.appliance', 2) }}</span>
<!-- "Appliances" -->

In JavaScript:

this.$t("phrases.somethingWentWrong")
this.$tc("words.meter", 2)

How to update existing translations

When you add a new feature or change existing UI text, you need to update all locale files:

1. Add or modify the key in en.json first. English is the source of truth. Pick the appropriate section (words for single reusable words, phrases for longer UI strings, messages for notifications, menu for navigation).

2. Add the same key to every other locale file (fr.json, pt.json, ar.json, bu.json). If you don't know the correct translation, add the English text as a placeholder and flag it for a translator — an English fallback is better than a missing key that shows a raw key string in the UI.

Checking and fixing translation files

CI verifies that every locale file is deep-sorted and has the same keys as en.json. Run these from src/frontend/:

npm run i18n:check-json    # verify sorting and key parity (what CI runs, as `npm run lang:check`)
npm run i18n:fix-json      # sort and format all locale files in place
npm run i18n:translate-json   # fill keys missing from a locale via Google Translate (local use only, not run in CI)

i18n:translate-json fills locale keys that are missing relative to en.json, via the Google Cloud Translation API.

1. Get an API key. Create one in the Google Cloud Console, with the Cloud Translation API enabled on a billed project.
2. Add it to dev/.env.micropowermanager-frontend as GOOGLE_TRANSLATE_API_KEY.
3. Recreate the frontend container so it picks up the new variable: docker compose up -d frontend-dev. env_file is only read on container creation, so a plain docker compose restart won't pick it up.
4. Run the script inside the container, so it inherits that env: docker compose exec frontend-dev npm run i18n:translate-json. By default this fills every locale; pass a locale code to limit it to one, e.g. npm run i18n:translate-json -- pt. Pass --dry-run to list missing keys without translating — no API key required for that.

MPM Brand guidelines

To ensure a consistent look and feel across our applications, we maintain a set of brand guidelines covering typography, color palettes, iconography, and spacing.

When designing any user-facing UI elements, please consult the MPM Brand guidelines for styling direction. If you encounter a scenario not covered by the guidelines, feel free reach out!
